Kärcher SC 4 EasyFix Iron User Manual

12 English
Pressure controller
The pressure controller keeps the pressure in the steam
boiler as constant as possible during operation. The
heating is switched off when the maximum operating
pressure is reached in the steam boiler and is activated
if there is a pressure drop in the steam boiler as a result
of a steam removal.
Safety thermostat
The safety thermostat prevents the device from over-
heating. If the pressure regulator and the boiler thermo-
stat fail and the unit overheats, the safety thermostat
switches the unit off. Before resetting of the safety ther-
mostat, contact the responsible KÄRCHER Customer
Service.
Boiler thermostat
The boiler thermostat switches off the heating in the
event of a fault; for example, if there is no water in the
steam boiler and the temperature in the steam boiler ris-
es.
As soon as you refill the water, the device is ready for
use again.
Maintenance lock
The maintenance lock seals the steam boiler from the
steam pressure present. The maintenance cap is also a
pressure relief valve. If the pressure regulator is defec-
tive and the steam pressure in the steam boiler rises,
the pressure relief valve opens and steam is escapes
through the lock.
Prior to restarting the device, contact the responsible
KÄRCHER Customer Service.
Device description
The maximum amount of equipment is described in
these operating instructions. Depending on the model
used, there are differences in the scope of delivery (see
packaging).
For the figures, please refer to the graphics page
Illustration A
1 Unit plug with cover
2 Water reservoir
3 Filling hole, water reservoir
4 Switch - On
5 Switch - Off
6 Indicator light (green) - heating
7 Indicator light (red) - water shortage
8 Carrying handle
9 Holder for accessories
10 Holder for accessories
11 Maintenance lock
12 Storage for mains connection
13 Park bracket for floor nozzle
14 Mains connection cable with mains plug
15 Non-driven wheels (2 x)
16 Steering roller
17 Steam gun
18 Steam lever
19 Unlocking button
20 Selector switch for steam volume (with child lock)
21 Steam hose
22 Steam connector
23 Spotlight nozzle
24 Round brush (small)
25 **Power nozzle
26 **Round brush (large)
27 Manual nozzle
28 Manual nozzle microfibre cover
29 Extension tubes (2 x)
30 Unlocking button
31 Floor nozzle
32 Hook and loop fastener
33 Microfibre floor cloth (1 x)
34 **Microfibre floor cloth (2 x)
35 **Carpet glider
36 Descaler
37 Steam pressure iron
38 Indicator light (orange) - heating
39 “Steam” switch (top)
40 Lock for steam switch
41 “Steam” switch (bottom)
42 Temperature controller
43 Steam connector
** SC 4 EasyFix Premium Iron
Installation
Installing accessories
1. Insert and engage the steering roller and non-driven
wheels.
Illustration B
2. Open the cover on the device socket.
Illustration E
3. Connect the steam connector to the device socket
so that the steam connector audibly engages.
Illustration E
4. Push the open end of the accessory onto the steam
gun so that the unlocking button on the steam gun
engages.
Illustration J
5. Push the open end of the accessory onto the spot-
light nozzle.
Illustration K
6. Connect the extension tubes with the steam gun.
Risk of scalding from steam
Read operating instructions

Kärcher SC 4 EasyFix Iron Specifications

General

Type	Portable steam cleaner
Capacity	0.5 L
Cord length	4 m
Hose length	2.3 m
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Cord storage	Yes
Steam-ready light	-
Ready time	4 min
Steam pressure	3.5 bar
Included brush type	Round cleaning brush

Weight and Dimensions

Depth	251 mm
Width	380 mm
Height	273 mm
Weight	4000 g
Package weight	7900 g
