8 English 9.764-892.0 Rev. 00 (07/17)
1 Screws
2 Steering roller
Unscrew the screws.
1Hood
2 Installation tools
Open the hood using the installation tool.
Remove the hood.
See:
AHNK Uninstall / install power cable
1 Handle
2 Suction hose
3 Screws
4 Cover
Unlock the handle.
Remove the handle from the suction hose.
Unscrew the screws.
Separate casing shells.
1 Casing shell
2 Screws
3 Suction hose
4Branch
5Spring
6 Release button
ABKA Remove/install the cable coiling device
ABSS Remove/install the suction hose

Other manuals for Kärcher VC 3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kärcher VC 3 and is the answer not in the manual?

Kärcher VC 3 Specifications

General IconGeneral
AC input voltage220-240 V
AC input frequency50 - 60 Hz
Maximum input power700 W
Annual energy consumption24.8 kWh
HEPA classHEPA 12
Proper useHome
Noise level76 dB
Cleaning surfacesCarpet, Hard floor
Vacuum air filteringHEPA
Dirt separating methodMulti cyclonic
TypeCylinder vacuum
Hose length1.5 m
Cleaning typeDry
Dust capacity0.9 L
Product colorBlack, Yellow
Dust container typeBagless
Cord length- m
Automatic cord rewinderYes
Dust container full indicator-
Number of nozzles2
Vacuum brushes includedCleaning brush
Weight and Dimensions IconWeight and Dimensions
Depth388 mm
Width269 mm
Height334 mm
Weight- g
Weight (without accessories)4400 g
