Kärcher VC 4s Cordless Instructions

14 English
Electric floor nozzle
 Attach the flat brush roller floor nozzle to clean hard
surfaces.
 Attach the soft brush roller floor nozzle (Plus) to
clean carpets and carpeted floors, etc.
Illustration H
One click to clear out dust
1. Press the button on the left to clear out dirt in one
s
tep.
Illustration I
Standard accessories
 Attach the fabric nozzle to clean upholstered furni-
ture, mattresses, laced curtains, etc.
 Attach the crevice nozzle.
Illustration J
Illustration K
1 This is used for cleaning joints, grooves between
doors and windows, tiny slits, etc.
2 This is used for cleaning delicate objects with care,
e.g. bookcases, handicrafts, etc.
Optional accessories
 Attach the mattress nozzle to clean mites / dust in
the mattresses and pillows, etc.
 Attach the dusting brush to clean wall surfaces, cur-
tains, gaps in furniture, etc.
You need to use the flexible hose to connect the
dusting brush and the handy vacuum cleaner.
 Attach the car nozzle to clean dirt / dust in the car,
etc.
You need to use the flexible hose to connect the car
nozzle and the handy vacuum cleaner.
Illustration L
Transport
The battery has been tested in accordance with the rel-
evant rules for international transport and can be
transported / shipped.
Storage
Note
 Store the appliance in a dry room.
 Consider the weight of the appliance when storing it.
1. Insert the storage holder into the storage base.
Illustration M
1 Storage holder
2 Storage base
2. Insert the appliance into the storage dock.
Illustration N
3. Put the crevice nozzle and the upholster brush into
accessory storage.
Care and maintenance
Note
 Use the appliance only when all filters and the dust
container are installed.
 Defective filters and filters that can no longer be
cleaned must be replaced.
Before doing any work on the appliance:
1. Switch off the appliance.
2. Unplug the power supply from the power outlet.
Cleaning the filter set and the dust container
ATTENTION
Incorrect cleaning of the EPA filter
Damage to the EPA filter
Do not wash the EPA filter.
Do not clean the EPA filter in a washing machine.
Do not dry the EPA filter with a hair dryer.
The EPA filter ensures clean exhaust air.
 Clean the EPA filter if it is visibly dirty.
 Replace the EPA filter if it is visibly damaged.
 We recommend replacing the EPA filter every 6
months based on your use of the device.
1. Unlock the dust container, and pull out the dust con-
tainer.
Illustration O
2. Remove the EPA filter, and unplug the cyclone body
and cyclone filter from the dust container.
Illustration P
3. Carefully empty / knock the dirt out of the EPA filter.
Illustration Q
4. Empty the dust container, and rub down inside it us-
ing a cloth.
Illustration R
5. Turn the cyclone body counterclockwise, and sepa-
rate the cyclone body from the cyclone filter.
Illustration S
6. Clean the cyclone body, cyclone filter and dust con-
tainer under running water.
Illustration T
7. Allow the cyclone body, cyclone filter and dust con-
tainer to dry completely.
Illustration U
8. Insert the cyclone body into the cyclone filter, and
turn the cyclone body clockwise to latch into place.
9. Insert the cyclone set into the dust container.
10. Install the EPA filter on the upper section of the cy-
clone set, and align.
11. Align the mounting point on the appliance with the
desired mounting hole on the dust container, and
latch the dust container into place.
Illustration V

Kärcher VC 4s Cordless Specifications

General

Noise level	79 dB
Cleaning type	Dry
Variable power	Yes
Number of speeds	3
Vacuum air filtering	HEPA
Dirt separating method	Multi cyclonic
Air filtration stages quantity	12
Battery type	Built-in
Power source	Battery
Charging time	3.5 h
Battery voltage	18 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Brush shape	Rectangular
Product color	Black, Yellow
Dust container type	Bagless
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	139 mm
Width	270 mm
Height	1110 mm
Weight	1300 g
