Kärcher VC 4s Cordless Instructions

16 English
Technical data
Subject to technical modifications.
1.198-280.0 1.198-282.0
Electrical connection
Power frequency Hz 50 - 60 50 - 60
Mains voltage V 100 - 240 100 - 240
Voltage of charger V 22 22
Working voltage of the battery V 18 18
Charging time when the battery is completely dis-
charged
min 180 ~ 240 180 ~ 240
Battery capacity mAh 2500 2500
Current consumption A 0.75 0.75
Battery type Li-ion Li-ion
Protection class II II
Nominal power W 220 220
Rated power (Handheld) W 190 190
Rated power (Floor nozzle) W 30 30
Device performance data
Dust container capacity l 0.3 0.3
Vacuum (min.) kPa 15 15
Operating time when battery is fully charged in
normal operation
min Energy saving mode: ≥ 60,
Medium speed mode: ≥ 30,
Full speed mode: ≥ 12
Energy saving mode: ≥ 60,
Medium speed mode: ≥ 30,
Full speed mode: ≥ 12
EPA-Filter EPA 12 EPA 12
Sound power level L
wA
dB(A) 79 79
Dimensions and weights
Weight (without accessories) kg 1.25 1.25
Length mm 270 255
Width mm 139 150
Height mm 1110 1110

Kärcher VC 4s Cordless Specifications

General

Noise level	79 dB
Cleaning type	Dry
Variable power	Yes
Number of speeds	3
Vacuum air filtering	HEPA
Dirt separating method	Multi cyclonic
Air filtration stages quantity	12
Battery type	Built-in
Power source	Battery
Charging time	3.5 h
Battery voltage	18 V
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Brush shape	Rectangular
Product color	Black, Yellow
Dust container type	Bagless
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	139 mm
Width	270 mm
Height	1110 mm
Weight	1300 g
