1. Overview
The KAT KTMP1 is a self-contained electronic percussion instrument with four drum pads, 50 sounds, audio and
trigger I/O. The product is mountable using the included Module Mount or a standard snare drum stand for use in
drum, percussion, and other performance setups.
The following is a list of the key features of the design:
• Portable compact drum pad unit with 50 high quality sounds
• Affordable and extremely versatile
• Four natural feel velocity sensitive rubber pads
• Hi-Hat and Bass Drum Pedal input allows you to play this as a drum kit
• Sounds can be tuned to your preference as well as panning and reverb control
• USB and MIDI output allows for PC connectivity to play parts right into your DAW or trigger external sound sources
• Ideal for stage and studio use
2. Panel Description
2.1 Front Panel Description
1. Power Button:
Press the button to turn the power on/off
2. Drum Pad LED Display:
Indicates the pad you want to adjust
3. [Value +] and [Value -] buttons:
Adjust the parameters, such as voice number, level, pan, tune, reverb, sensitivity, midi note
4. LED Display:
2-Digi-LED
5. [SELECT +] and [SELECT -] buttons:
Select the (mode) parameter you want to adjust
6. Mode LED Display:
Indicates the mode you want to adjust
7. Volume knob:
Adjust the main volume
8. Drum Pads:
4 drum pads
