Bearing removal
1. Remove the endbracket(s) to expose the bearing(s).
2. Use a puller to remove the bearing from the shaft end with a cap. If
the bearing is going to be used again, make sure the puller supplies
pressure only against the bearing inner ring (see Figure 29).
Puller against
bearing
Cap to protect shaft end
Outer ring
Inner ring
Figure 29: Bearing removal
