■ Contents
■ Specifications
88 Keys, Advanced Hammer Action IV
Maximum 96
27
Piano 1, Piano 2, Electric Piano, Drawbar, Church Organ, Harpsi & Mallets, Strings,
Choir & Pad, Bass
Reverb (5), Chorus, Tremolo, Delay (3), Rotary (2)
Equal (Piano Only), Mersenne pure (Major), Mersenne pure (minor), Pythagorea, Meantone,
Werckmeister III, Kirnberger III, Equal (flat), Equal
2 Tracks, 3 Songs
The total memory capacity of the recorder is approximtely 15,000 notes.
Concert Magic (88 Preset Songs), Volume, Dual, Split, Balance Slider, Lesson Function,
Metronome, Transpose, Tune, Lower Octave Shift, Lower Pedal On/Off,
Touch Curve (Light 1, Light 2, Normal, Heavy 1, Heavy 2, Off),
MIDI (16 part multi-timbral capability)
Sustain, Sostenuto, Soft
Headphones (2), LINE IN (L, R), LINE OUT (L/MONO, R), MIDI (IN, OUT)
16 W x 2
16 cm x 2
50 W
Rosewood, Mahogany, European Cherry
1392 x 470 x 827 mm
55” x 19” x 33”
42.5 kg, 94 lbs
Keyboard
Polyphony
Number of Sound
Sound Categories
Effects
Temperaments
Recorder
Other Features
Pedals
Jacks
Output Power
Speakers
Power Consumption
Finish
Dimensions (W x D x H)
(without Music Rack)
Weight (without bench)
* Specifications are subject to change without notice.
Specifications................................................................... 2
Hardware List ................................................................... 3
Case Assembly ................................................................ 4
Key Cover Assembly ........................................................ 5
Stand Assembly ............................................................... 6
Panel Assembly ............................................................... 7
Top Board Assembly ........................................................ 8
Keyboard Unit (RG88 Type) ............................................. 9
Keyboard Disassembling Procedure ............................. 10
Electronic Parts List ....................................................... 11
P.W.B. KEP-126 (11)(12) Assembly Parts List .............. 12
P.W.B. KEP-058 ~ 061 (4) Assembly Parts List ............ 13
P.W.B. KEP-064 ~ 068 (26)(27) Assembly Parts List .... 14
Cable Wiring Specification ............................................. 16
Block Diagram ................................................................ 17
P.W.B. KEP-126 (11) Assembly [TOP] ........................... 18
P.W.B. KEP-126 (11) Assembly [BACK] ........................ 19
P.W.B. KEP-126 (12) Assembly [TOP] ........................... 20
P.W.B. KEP-126 (12) Assembly [BACK] ........................ 21
P.W.B. KEP-126 Circuit 1/4 ............................................ 22
P.W.B. KEP-126 Circuit 2/4 ............................................ 23
P.W.B. KEP-126 Circuit 3/4 ............................................ 24
P.W.B. KEP-126 Circuit 4/4 ............................................ 25
P.W.B. KEP-058 – 061 (4) Assembly ............................. 26
P.W.B. KEP-058 – 061 Circuit 1/3 .................................. 27
P.W.B. KEP-058 – 061 Circuit 2/3 .................................. 28
P.W.B. KEP-058 – 061 Circuit 3/3 .................................. 29
P.W.B. KEP-064 – 068 (26) Assembly ........................... 30
P.W.B. KEP-064 – 068 (27) Assembly ........................... 31
P.W.B. KEP-064 – 068 Circuit 1/3 .................................. 32
P.W.B. KEP-064 – 068 Circuit 2/3 .................................. 33
P.W.B. KEP-064 – 068 Circuit 3/3 .................................. 34
P.W.B. KKB-015 Circuit .................................................. 35
Key Switch Matrix .......................................................... 36
