Kawai CS8 - Jack Panel Parts

P19 Jack Panel Parts
CS8
No.
Qty
①
1
②
2
③
1
④
1
⑤
4
⑥
4
⑦
3
⑧
2
⑨
2
Parts Code
Parts Name
Remarks
954322
JACK PANEL
=CS9
937260
JACK PANEL STAY R
239079B
PWB E ASSY. KEP-586(3) [JACK]
238999
PWB E ASSY. KEP-502(3) [MIDI-USB]
798030
+Binding Taptite Screw S Tite 3mm*8mm WHC or BKC
811187
NON WOVEN FABRIC HN611B adhesive backing t0.55*10*49
798007
+Binding Taptite Screw S Tite 3mm*8mm BKC
+Binding Taptite Screw P Tite 3mm*10mm BKC
798509
VOLUME NUT M12 BKC
798425
