KB Electronics KBPW-240D User Manual

INSTALLATION AND OPERATING INSTRUCTIONS
MODEL KBPW-240D
KB Part No. 8401 (Black Case) • Part No. 8402 (White Case)
NEMA 4X, IP-65
PWM DC Motor Speed Control For PM and Shunt Wound Motors
Rated 7.5 Amps DC, 11.5 Amps AC @ 115/230 VAC
See Safety Warning on Page 2
The information contained in this manual is intended to be accurate. However, the manufacturer retains
the right to make changes in design which may not be included herein.
BRK
REV
FWD
%
100
90
80
70
60
50
40
30
20
10
0
NEMA-4X / IP-65
START
STOP
RUN
JOG
PWM DC MOTOR SPEED CONTROL
PENTA-DRIVE
™
OLSTOPON
™
!
™
A COMPLETE LINE OF MOTOR DRIVES
© 2000 KB Electronics, Inc.
Pending
