KB Genesis KBAC-27D - KBAC-27 D, 29, 29 (1 P), 45, 48 Control Layout

11
Figure 3 – KBAC-27D*, 29, 29 (1P), 45, 48 Control Layout
1
P1P2P3
CON2
STATUS POWER
LED Board
FWD COM REV RUN COM STOP
MIN ACCELMAX CLDEC/I BOOST JOG COMP
MIN ACCELMAX CLDECEL BOOST JOG COMP
Start/Stop Switch
Black
White
Red
White (Low)
Violet (High)
Orange (Wiper)
Main Speed Potentiometer
N.C.
TB2
N.O. COM
E 1/2
A 2
C 1 D 3/4 B 1 1/2
J2
M A
J3
2X 1X
J4
60Hz 50Hz
J5
ADJ FIX
J6
RG INJ
J7
R F
J8
NC NO
J9
CT VT
J10
2 B 1 A
J11
CON1
All jumpers and trimpots are shown in factory set positions.
*On Model KBAC-27D, J11 is Labeled "A" , "B"
*On Model KBAC-27D, J12 is Labeled "2", "1 1/2", "1", "3/4", "1/2"
JOG
