KB Genesis KBAC-29 - Models KBAC-27 D, 29, 29 (1 P), 45, 48 Mechanical Specifications

16
Figure 6 – Models KBAC-27D, 29, 29 (1P), 45, 48 Mechanical Specications (Inches/mm)
2.97
75.4
3.07
77.9
7.36
187
3.20
81.3
1.60
40.6
1.60
40.6
0.875
22.2
1.09
22.2
2X
8.67
220
9.24
235
9.82
249
7.30
185
7.69
195
4X Ø
6.4
0.25 0.29
7.37
2X
25.4
2X
80.0
1.00
3.15
2X
*Tighten these screws, in the sequence shown, to 12 in-lbs (14 kg-cm).
AC MOTOR SPEED CONTROL
KBAC SERIES • NEMA 4X / IP 65
Hybrid Drive
™
2* 3*
4* 1*
