KB Genesis KBAC-45 User Manual

9
Table 2 – Optional Accessories
Description KBAC-24D KBAC-27D KBAC-29 KBAC-29 (1P) KBAC-45 KBAC-48
KBAC-217 Series
KBAC-416 Series
Forward-Stop-Reverse Switch – Provides motor
reversing and stop functions. Mounts on the enclosure
cover and is supplied with a switch seal to maintain
liquidtight integrity.
9480 9480 9480 9480 9480 9480 8888
On/O AC Line Switch – Disconnects the AC Line.
Mounts on the enclosure cover and is supplied with a
switch seal to maintain liquidtight integrity.
9482 9523 9532 9532 9532 9532
“S” Sux Models
(Factory Installed
Only)
Run-Stop-Jog Switch – Selects speed
setting from either the Main Speed Potentiometer or
the JOG Trimpot. Mounts on the enclosure cover and
is supplied with a switch seal to maintain liquidtight
integrity.
9340 9340 9340 9340 9340 9340 8889
SIAC-PS Signal Isolator with Power Supply –
Provides isolation between a non-isolated signal source
and the drive. Mounts on the drive’s PC board with
four snap-ins.
9600C* 9600C* 9600C* 9600C* 9600C* 9600C* 8890
Auto/Manual Switch – When used with the Signal
Isolator, it selects remote process signal or the Main
Speed Potentiometer. Mounts on the enclosure
cover and is supplied with a switch seal to maintain
liquidtight integrity.
9481 9481 9481 9481 9481 9481 8891
AC Line Filter* – Provides Class A RFI (EMI)
suppression. Installs onto the drive’s PC board
with quick-connect terminals.
“S” Sux: Filter is used when On/O AC Line
Switch is installed.
“NS” Sux: Filter is used when On/O AC Line
Switch is not installed.
“S”
Sux
9507 9512 9479 — 9479 9479
9516
“NS”
Sux
9507 9512 9515 — 9515 9515
Liquidtight Fittings – Provide a liquidtight seal for
wiring the drive. Kit includes three 1/2” and one 3/4”
liquidtight ttings for case A and case B drives, and one
1/2” and two 3/4” liquidtight ttings for case C drives.
9526 9526 9526 9526 9526 9526 8892
* Complies with CE Council Directive 89/336/EEC Industrial Standard.
*Warning! It is highly recommended that the SIAC-PS Signal Isolator with Power Supply be
installed when using the drive with external control signals. See Appendix A, on Page 33,
for more information.
