be 100% (you may set some EXP to make better feel) , the signal should be set to 1.5ms

neutral. If you are using the built-in gyro of Flymenotor 3D, all mixers related to rudder must

be turned off.

Diagram 3.1.1 Ensure no mixing mode

Reciever

BEC

Battery

*Attention: it is FUTABA remote system, if you are using JR remote system, please link

servo to 2/3/4/6 channel.

To ensure you have turned off all mixer properly, you should make a test system like

diagram3.1.1 when you haven` t connected with the flymentor 3D. After powering up, move

the stick on, if the four directions of the two sticks affects only one servo, that prove the mixers

are all turned off successfully.

Please read manual of transmitter carefully before operating.
