14
Diagram 3.2.2 Electronic connection
Siehe nächs te
Tabelle
Flymentor 3D
Connector
Connector Name
FUTABA
Receiver
JR
Receiver
Comment
Black/Red/White
Three pins
Yellow solo pin
Aileron/Power connector
Elevator connector
Channel 1
Must connected
Receiver
Battery
BEC
ESC
Tail
Servo
Servo1
Servo2
Servo3
Servo4
Flymentor
3D
Orange solo pin
Pitch connector
Channel 6
Channel 2
Channel 2
Channel 3
Must connected
Channel 6
Must connected
Gray solo pin
Blue solo pin
Rudder connector
Gyro
connector
sensitivity
Channel 4
Channel 5
Optional, see 4.1.1
Green solo pin
Flymentor 3D
sensitivity connector
Channel 7
Optional, see 4.2.2
Channel 4
Must connected
Channel 5
Channel 7
