KE2 Therm Solutions 20844 User Manual

Q.1.3 November 2017
Page 8
KE2 EvaporatorEfciency
Quick Start Guide
© Copyright 2017 KE2 Therm Solutions, Inc., Washington, Missouri 63090
BL/BK
OR/BK
Y/BK
FAN/S
HEATERS
LL SOLENOID/COMP RELAY
BK/OR
L1
WT/R
L2
HS
GND
P/N 20996
12 AMP
20 AMP
3 AMP
OR NEUTRAL HEATERS
thermsolutions
®
NO NC
COM
NO NC
COM
COM
NC NO
COM
NC
N0
Solenoid Relay
Defrost Relay Fan Relay
208-240
Power Input
Voltage Jumper
208-240 Default
L1
Ground
L2
COM
NC NO
COM
NC
N0
Auxiliary Relay
Yellow with black stripe
16 AWG
Black with yellow stripe
(L1) 16 AWG
Blue with black stripe
12 AWG
Black with blue stripe
(L1) 12 AWG
LLS/Compressor
Fans
Black with white
(L1) 16 AWG
White with red
(L2/neutral) 16 AWG
Green
(Ground) 16 AWG
Power
Orange with black stripe
12 AWG
Black with Orange stripe
(L1) 12 AWG
Defrost Heaters
Supply Voltage
FAN
MOTOR
FAN
MOTOR
FAN
MOTOR
EVAPORATOR
FANS
HEATER LIMIT SWITCH
DEFROST HEATERS
LIQUID LINE SOLENOID
N.C.
R/W
BL/BK
BK
BL/BK
FROM
CONTROLLER
EC MOTOR
RELAY
Wiring Schematic - Controller New Installation
Wiring Schematic - Controller New Installation

KE2 Therm Solutions 20844 Specifications

General

Brand	KE2 Therm Solutions
Model	20844
Category	Controller
Language	English
