KE2 Evaporator Efficiency User Manual

© Copyright 2021 KE2 Therm Solutions, Inc., Washington, Missouri 63090
Q.1.64 July 2021
Page 2
KE2 EvaporatorEciency
Condensed Quick Start Guide
BL/BK
OR/BK
Y/BK
FAN/S
HEATERS
LL SOLENOID/COMP RELAY
BK/OR
L1
WT/R
L2
HS
GND
P/N 20996
12 AMP
20 AMP
3 AMP
OR NEUTRAL HEATERS
thermsolutions
®
NO NC
COM
NO NC
COM
COM
NC NO
COM
NC
N0
Solenoid Relay
Defrost Relay Fan Relay
208-240
Power Input
Voltage Jumper
208-240 Default
L1
Ground
L2
COM
NC NO
COM
NC
N0
Auxiliary Relay
Yellow with black stripe
16 AWG
Black with yellow stripe
(L1) 16 AWG
Blue with black stripe
14 AWG
Black with blue stripe
(L1) 14 AWG
LLS/Compressor
Fans
Black with white
(L1) 16 AWG
White with red
(L2/neutral) 16 AWG
Green
(Ground) 16 AWG
Power
Orange with black stripe
12 AWG
Black with Orange stripe
(L1) 12 AWG
Defrost Heaters
Supply Voltage
FAN
MOTOR
FAN
MOTOR
FAN
MOTOR
EVAPORATOR
FANS
HEATER LIMIT SWITCH
DEFROST HEATERS
LIQUID LINE SOLENOID
N.C.
R/W
BL/BK
BK
BL/BK
FROM
CONTROLLER
EC MOTOR
RELAY
See Q.1.30 Figure 3 for wiring of the EC Motor Relay.
Wiring Schematic - Controller New Installation
Wiring Schematic - Controller New Installation
Q
Use Split Bushing ("Q" in the kit) to prevent chang of the high volt- age wires if routing through the high voltage shield
