GB - 26
CP.30 Analog output 1 / function
CP.30 denes the function of analog output 1. The output at the analog output is always
made in a range of 0…+10 V. Negative values are inverted and the output is displayed in
a positive value.
Value Function Scaling factor
0…100 % (0…±100 %)
0 Absolute actual frequency CP.1 0…100 Hz
1 Absolute set frequency CP.2 0…100 Hz
2 Actual frequency CP.1 0…±100 Hz
3 Set frequency CP. 2 0…±100 Hz
4 Output voltage CP.9 0…500 V
5 DC link voltage CP.7 0…1000 V
6 Apparent current CP.4 0…2 • rated current
7 Active current ru.17 0…2 • ±rated current
8…10 reserved –
11 Absolute active current ru.17 0…2 • rated current
12 Power stage temperature ru.38 0…100 °C
13…21 reserved –
22 Analog input before amplication (ru.27) 0…100 %
23 Analog input after amplication (ru.28) 0…400 %
24…25 reserved –
26 Active power ru.81 0…±2 • Rated power
CP.32 Transistor output / function (term. X2A.10)
The switching level of CP.32 is pre-set to 4,00. Value range see CP.33.
CP.33 Relay output 1 / function (terminals X2A.11...13)
The switching level of CP.33 is adjusted by CP.34.
Value Function
0 No function (generally off)
1 Generally on
2 Run signal; also by DC-braking
3 Ready signal (no error)
4 Fault relay
5 Fault relay (without auto-reset)
6 Warning or error message at abnormal stopping
7 Overload pre-warning (OL)
8 Overtemperature pre-warning (OH)
9 External overtemperature
10 Motor protection pre-warning (OH2)
11 Interior temperature pre-warning (OHI)
12 Cable breakage 4...20 mA on analog input 1
14 max. constant current (Stall, CP.25) exceeded
15 max. ramp current (LA-Stop, CP.24) exceeded
16 DC-braking active
20 Actual value = set value (CP.3 = Fcon; rcon; not at noP, LS, error, SSF)
21 Accelerate (CP.3=FAcc, rAcc, LAS)
22 Decelerate (CP.3 = FdEc, rdEc, LdS)
further on next side
