Value Function
23 Real direction of rotation = set direction of rotation
24 Utilization (CP.6) > switching level
25 Active current > switching level
26 Intermediate circuit voltage (CP.7) > switching level
27 Real value (CP.1) > switching level
28 Set value (CP.2) > switching level
31 Absolute set value at AN1 > switching level
34 Set value at AN1 > switching level
40 Hardware current limit activated
41 Modulation on
44 Inverter status > switching level
47 Ramp output value > switching level
48 Apparent current (CP.4) > switching level
49 Forward running (not at nOP, LS, abnormal stopping or error)
50 Reverse running (not at nOP, LS, abnormal stopping or error)
63 Absolut ANOUT1 > switching level
65 ANOUT1 > switching level
73 Absolute active power > switching level
74 Active power > switching level
80 Active current > switching level
84 Actual value < minimum setpoint
No listed values are only for the application mode.
CP.35 AN1 Set value selection
The setpoint input (AN1) of the control can be triggered with different signal levels. In order
to correctly evaluate the signal, this parameter must be adapted to the signal source.
Value Set value signal
0 0…10 V DC / Ri = 29 kΩ
1 0…20 mA DC / Ri = 500 Ω
2 4…20 mA DC / Ri = 500 Ω
CP.36 Select 50/60Hz mode (only housing B)
When units or machines are delivered in the area of application of UL an adaption of the
factory setting to the valid operating data there can be done with this parameter.
Value Default value
0 Current values and limts, motor data, frequencies and speed relate to a 50 Hz
mains with 400 V rated voltage.
1 Current values and limts, motor data, frequencies and speed relate to a 60 Hz
mains with 460 V rated voltage.
To Next Page
