CP 503/A, CP 505/A,D,K, CP 507/
A,C
Description of the module
Project engineering manual V1.06
16
© KEBA 2021
3.2 Side view
Fig.3-2: Left side view
1 ... Locking hooks, expansion module 2 ... Area for type plate printing
3 ... Area for connection diagram print-
ing
4 ... Mounting rail locking
5 ... Expansion bus 6 ... Area for symbol printing
