KEF PSD 5 - Page 19

18
Spare parts list for PSD 5 belt arm
Order number
Pos. Nr.
Type
Right
Left
1
Top screw
2078212
2078212
2
Sliding pipe for belt stand
9480687
9480687
3
Machine screw M4x4 Z
0737618
0737618
4
Lock ring DIM 42, DIN 472
7655123
7655123
5
Ball bearings 6302 2Z
1462846
1462846
6
Distance pipe ø22/15x10
2155002
2155002
7
Top roll
9480681
9480681
8
Shaft for top roll
2078200
2078200
9
Disc for top roll
9480693
9480693
10
Screw M6x16 CH Z lowered head
0120625
0120625
11
Pointed screw M5x10
0737605
0737605
12
Holder for top roll
9480679
9480679
13
Spring for telescope arm
9480694
9480694
14
Pipe for telescope arm
9480682
9480682
15
Spring holder for telescope arm
2078202
2078202
16
Handle for grinding belt M8x30
2078204
2078204
17
Pipe bushing for telescope arm
2078206
2078206
18
Pipe holder for telescope arm
9480692
9480692
19
Pipe cotter pin ø5x25
2078208
2078208
20
Håndle for adjustment of grinding belt
2188010
2188010
21
Fittings for telescope arm
1533813
1533813
22
Washer DIM 8 Z
0132594
0132594
23
Screw M8x25 CH Z
7676512
7676512
24
Distance ring
4318001
4318001
25
Pointed screw M8x12
0105026
0105026
26
Holder for telescope arm
2078211
2078211
27
Grinding system
0744425
0744409
28
Disc 3/8” Z
0101491
0101491
29
Screw M10x30 Z
0236005
0236005
30
Box cover for belt arm
1533780
1533781
31
Washer DIM 5 Z
0102555
0102555
32
Screw M5x10 CH Z
0120628
0120628
33
Felt washer
1533816
1533816
34
Cover plate
1533812
1533812
35
Distance ring ø30/20x6mm
1551176
1551176
36
Collar bushing PSD 5
0995681
0995681
37
Star handle ø40 M8 DIN 6335
1443593
1443593
38
Auto disc 5/16” Z
5437850
5437850
39
Spark arrestor
1533808
1533808
40
Nut M5 Z
0737623
0737623
41
Flange inner
0921572
0921572
42
Contact wheel 200x50x20
1532170
1532170
43
Square table
1533807
1533818
44
Flange outer
1105183
1105183
45
Double sticking tape
2004899
2004899
46
Graphite pad 50x270
2004898
2004898
47
Nut M20x1.5
0744824
0744816
48
Grinding belt
0215080
0215080
50
DN-bearing ring for belt arm
0120510
0120510
