Keiser 1021 - Equipment Specifications; Air Storage Tank Specifications

1021 | 1022 SMALL AIR COMPRESSOR
04
Dimensions and features for both models:
• Motor: 3/4 HP
• Air Storage Tank Capacity: 2.5 gallons (9.5 L)
• Equipment Capacity: Up to 8 Keiser pneumatic machines
Based on normal operating conditions
• Pressurized Air Delivery Range: 100–120 psig (6.89–8.27 bar)
• Lubrication Type: Oil-less (requires no lubrication)
• Decibel Rating: 61–63 dB
Under normal operating conditions, distance of 39.37 inches (1 m)
EQUIPMENT SPECIFICATIONS
26 inches
(661 mm)
14 inches
(356 mm)
82 lbs
(37 kg)
16 inches
(407 mm)
Air Storage Tank
The equipment contains four air storage tanks (air accumulator)
with the following operating parameters:
Maximum working pressure: 125 psi (8.6 bar)
Maximum working temperature: 104ºF (40ºC)
Minimum working temperature: 32ºF (0ºC)
Maximum vessel capacity: 140 in
3
(2.29 L) per tank
Model 1021 Model 1022
Voltage: 115V~ 230V~
Current: 5A 2.5A
Frequency: 60 Hz 50 Hz
