In this section:

Introduction .............................................................................. 3-1

Signal limitation ........................................................................ 3-1

Scanner card detection ............................................................ 3-2

Basic front-panel measurements .............................................. 3-2

Typical applications .................................................................. 3-7

Measurement considerations ................................................. 3-14

Introduction

This section contains detailed information on front panel and remote interface operation of the

2001-TCSCAN.

Before using the 2001-TCSCAN, you should be thoroughly familiar with the operation of the

DMM6500 multimeter. See the DMM6500 User's and Reference Manuals for the necessary

information.

Signal limitation

To prevent overheating or damage to the relays, never exceed the following maximum input signal

levels:

• DC signals

 110 V DC

 1 A switched

 30 VA (resistive load)

• AC signals

 125 V

RMS

or 175 V AC

PEAK

 1 A switched

 62.5 VA (resistive load)

Channels 5 and 10 have a maximum power of 0.25 VA due to factory-installed, current-limited

resistors.

Before using the 2001-TCSCAN, you should be thoroughly familiar with the operation of the

DMM6500 multimeter. See the DMM6500 User's and Reference Manuals for more information.

Section 3

Operation
