Keithley 2001-TCSCAN User Manual

Section
2: Card connectors and installation Model 2001-TCSCAN Scanner Card User
's Manual
2-12 2001-TCSCAN-900-01 Rev. A / April 2018
Scanner card installation
Turn off power to all instruments (including the multimeter), and disconnect all power cords.
Make sure all power is removed and any stored energy in external circuitry is discharged.
To prevent contamination of the 2001-TCSCAN that could degrade performance, handle the scanner
card by the edges and covers only.
The figure below demonstrates the 2001-TCSCAN installation.
Figure 9: Unlock card
