Keithley 2001-TCSCAN User Manual

Model 2001
-TCSCAN Scanner Card User's Manual Section 3:
Operation
2001-TCSCAN-900-01 Rev. A / April 2018 3-3
From the 2001-TCSCAN channel list, select the box next to the channel number to open or close
it. Selecting the channel box again will open the channel, and the connection icon will move to
the open state.
Fi
gure 12: DMM6500 channel list
2. When closing a channel, select the measurement function for that channel from Measure
Functions screen. Note that you will select a measurement function for each channel you close.
Figure 13: Measurement function screen
3. Select OK.
