Keithley 2200 Series User Manual

Specifications
Table 1 : Series 2200 specifications (cont.)
Parameter Description
Voltage transient
response settling
time, load change,
typical
<150 ms to within 75 mV following a change from 0.1 A to 1 A.
Voltage transient
response settling
time, setting
change, rising,
typical
<150 ms from beginning of excursion to within 75 mV of terminal value following a change from 1 V to 11 V
intoa10Ω resistor.
Voltage transient
response settling
time, setting
change, falling,
typical
<150 ms from beginning of excursion to within 75 mV of terminal value following a change from 11 V to
1Vintoa10Ω resistor.
2200-30-1
Line Selection
Switch
Voltage Frequency Fuse Rating Max VA +
110V
110/115/120 50/60 Hz
6.3A TH 250V 350
220V
220/230/240 50/60 Hz
3.15A TH 250V 350
2200J-30-1
Line Selection
Switch
Voltage Frequency Fuse Rating Max VA +
110V 100
50/60 Hz
6.3A TH 250V 350
Unit SpecificMains
Requirements
220V 200
50/60 Hz
3.15A TH 250V 350
Maximum Input VA,
typical
350 VA
Table 2: 2230-30-1 and 2230J-30-1 specifications for Channels 1 a nd 2
Parameter Description
Channel 1 and 2, nominal Channels 1 and 2 are symmetrical and isolated. They are primarily targeted at powering analog
circuits operating around ground.
Constant Voltage Operation,
nominal
The unit may be set to be a constant voltage over a range of currents.
Voltage Range
The output voltage may be adjusted from 0V to 30V.
Series 2200 Multichannel Programmable DC Power Supplies Technical Reference 3
