Performance Ve rification
Table 20: DC cur
rent accuracy
Instrument test
current Test voltage DUT current Min Measured current Max
Channel 1
0%
15 V 0.00000000 A -0.00500000 A
__________
0.00500000 A
25%
15 V 0.3750 A 0.36963 A
__________
0.38037 A
50%
15 V 0.75000 A 0.74425 A
__________
0.75575 A
75%
15 V 1.1250 A 1.11888 A
__________
1.13113 A
100%
15 V 1.5000 A 1.49350 A
__________
1.50650 A
Channel 2
0%
15 V 0.00000000 A -0.00500000 A
__________
0.00500000 A
25%
15 V 0.3750 A 0.36963 A
__________
0.38037 A
50%
15 V 0.7500
0A
0.7442
5A
______
____
0.7557
5A
75%
15 V 1.1250 A 1.11888 A
__________
1.13113 A
100%
15 V 1.5000 A 1.49350 A
__________
1.50650 A
Channel 3
0%
3 V 0.00000000 A -0.00500000 A
__________
0.00500000 A
25%
3 V 1.25000000 A 1.24375000 A
__________
1.25625000 A
50%
3V 2.
50000000 A
2.
49250000 A
__
________
2.
50750000 A
7
5%
3 V 3.75000000 A 3.74125000 A
__________
3.75875000 A
100%
3 V 5.00000 A 4.99000 A
__________
5.01000 A
20 Series 2200 Multichannel Programmable DC Power Supplies Technical Reference
