Keithley 2200 Series - Table 18: DC Voltage Line Regulation; Table 19: DC Voltage Load Regulation

Performance Verification
Table 18: DC vol
tage line regulation
Instrument M in line Max line Nom line Nom – Min Max – Nom Largest Max value
Channel 1
_________ _________ _________ _________ _________ _________
0.0120000 V
Channel 2
_________ _________ _________ _________ _________ _________
0.0120000 V
Channel 3
_________ _________ _________ _________ _________ _________
0.0072000 V
Table 19: DC voltage load regulation
Instrument Min load Ref load Max load Ref – Min
Max –
Ref
(Max–Ref)
/ 0.98 Largest
Max
value
Channel 1
_______ _______ _______ ________ ________ ________ _______
0.0120000 V
Channel 2
_______ _______ _______ ________ ________ ________ _______
0.0120000 V
Channel 3
_______ _______ _______ ________ ________ ________ _______
0.0072000 V
Series 2200 Multichannel Programmable DC Power Supplies Technical Reference 19
