Programmable Power Supplies Verification and Adjustment Manual Section 8:
Constant voltage adjustment
077104802 / November 2016 8-5
The display will indicate "OK" when the adjustment is complete for approximately five seconds.
Additionally, the output turns on and the CV indicator is lit. Also, the instrument automatically returns
to C110 after the automatic OVP adjustment ends.
18. Rotate the voltage knob to go to save mode (C130).
19. Rotate the current knob until "1" is shown on the bottom display (C130:1)
20. Press the voltage knob to save the adjustment results.
The display will indicate "OK" and the instrument will automatically return to "C000" when the
adjustment value is saved.
21. Rotate the current knob to go to "exit adjustment" mode (C000:2).
