When making two-wire connections to the Series 2280, you
must short both Output Hi and Sense Hi and Output Lo and
Sense Lo with the shorting jumpers. If you do not do this, the
display will show incorrect voltage output readings.
Failure to install the cable housing may result in
personal injury or death due to electric shock.
The following illustration shows two-wire (local sensing) DUT
connections to the rear panel.
After making the connections, slide the cover over the
rear-panel mating connector and wires.
