Keithley Instruments, Inc.
Cleveland, Ohio 44139
DRN.
CKD.
APP.
DATE
DATE
DATE
PART NUMBER
LTR REVISIONS APP. DATE
FORM 28777A-SBG
BRUNING 40-21 62198-SBG
SPECIFICATIONS
SPEC-2440
A 25977 Released SZ 5/22/01
B 27103 Revised SZ 5/20/02
C 28003 Revised SZ 3/17/03
HW 5/22/01
SZ 5/22/01
HW 3/26/03
Rev. C
Page 1 of 3
2440 and 2440-C SourceMeter
®
Specifications
SOURCE SPECIFICATIONS
VOLTAGE PROGRAMMING ACCURACY (LOCAL OR REMOTE SENSE)
RANGE
PROGRAMMING
RESOLUTION
ACCURACY (1 Year)
23°C ±5°C
±(% rdg. + volts)
NOISE
(peak-peak)
0.1Hz – 10Hz
200.000 mV 5 µV 0.02% + 600 µV 10 µV
2.00000 V 50 µV 0.02% + 600 µV 50 µV
10.0000 V 500 µV 0.02% + 1.2 mV 250 µV
40.0000 V 5 mV 0.02% + 4.8 mV 1 mV
TEMPERATURE COEFFICIENT (0°-18°C & 28°-50°C): ±(0.15 × accuracy specification)/ °C.
MAX. OUTPUT POWER: 55W, four quadrant source or sink operation.
SOURCE/SINK LIMITS:
±10.5V @ ±5.25A, ±42V @ ±1.05A.
VOLTAGE REGULATION: Line: 0.01% of range. Load: 0.01% of range + 100
µV.
NOISE 10Hz – 1MHz (p-p): 50mV typical.
OVERVOLTAGE PROTECTION: User selectable values, 5% tolerance. Factory default = none.
CURRENT LIMIT: Bipolar current limit (compliance) set with single value. Min. 0.1% of range.
OVERSHOOT: <0.1% typical (full scale step, resistive load, 10mA range).
CURRENT PROGRAMMING ACCURACY (LOCAL OR REMOTE SENSE)
RANGE
PROGRAMMING
RESOLUTION
ACCURACY (1 Year)
2
23°C ±5°C
±(% rdg. + amps)
NOISE
(peak-peak)
0.1Hz – 10Hz
10.0000 µA 500 pA 0.033% + 2 nA 50 pA
100.000 µA 5 nA 0.031% + 20 nA 500 pA
1.00000 mA 50 nA 0.034% + 200 nA 5 nA
10.0000 mA 500 nA 0.045% + 2 µA 50 nA
100.000 mA 5 µA 0.066% + 20 µA 500 nA
1.00000
1
A 50 µA 0.067% + 900 µA 50 µA
5.00000
1
A 50 µA 0.10% + 5.4 mA 500 µA
TEMPERATURE COEFFICIENT (0°-18°C & 28°-50°C): ±(0.15 × accuracy specification)/ °C.
MAX. OUTPUT POWER: 55W, four quadrant source or sink operation.
SOURCE/SINK LIMITS:
±5.25A @ ±10.5V, ±1.05A @ ±42V.
CURRENT REGULATION: Line: 0.01% of range. Load: 0.01% (5 A range 0.05%) of range +
100
pA.
VOLTAGE LIMIT: Bipolar voltage limit (compliance) set with single value. Min. 0.1% of range.
OVERSHOOT: <0.1% typical (1mA step, RL = 10kΩ, 10V range).
ADDITIONAL SOURCE
SPECIFICATIONS
TRANSIENT RESPONSE TIME: 30µs minimum for the
output to recover to its spec. following a step change in load
.
COMMAND PROCESSING TIME: Maximum time
required for the output to begin to change following the
receipt of :SOURce:VOLTage|CURRent <nrf> command.
Autorange On: 10ms. Autorange Off: 7ms.
OUTPUT SETTLING TIME: Time required to reach 0.1%
of final value after command is processed. 100µs typical.
Resistive load. 10µA to 100mA range.
OUTPUT SLEW RATE (±30%):
0.25V/µs, 40V range, 100mA compliance.
0.08V/µs, 10V range, 100mA compliance.
DC FLOATING VOLTAGE: Output can be floated up to
±40VDC from chassis ground.
REMOTE SENSE: Up to 1V drop per load lead.
COMPLIANCE ACCURACY: Add 0.3% of range and
±0.02% of reading to base specification.
OVER TEMPERATURE PROTECTION: Internally
sensed temperature overload puts unit in standby mode.
RANGE CHANGE OVERSHOOT: Overshoot into a fully
resistive 100kΩ load, 10Hz to 1MHz BW, adjacent range
changes between 200mV, 2V, and 10V ranges, 100mV
typical.
MINIMUM COMPLIANCE VALUE: 0.1% of range.
1. Full power source operation regardless of load to 30°C ambient. For
above 30°C and/or power sink operation, refer to the Power
Equations section of the User’s Manual.
2. For sink mode, 10µA to 100mA range, accuracy is:
±(0.5% + offset*3)
For 1A and 5A range, accuracy is:
±(1.5% + offset*3)
