Keithley 2611B Reference Manual

Section
7: TSP command reference Series 2600B System SourceMeter® Instrument
Reference Manual
7-292 2600BS-901-01 Rev. B / May 2013
A set bit indicates the specified timer generated an action overrun because it was still processing a delay from a
previous trigger when a new trigger was received.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to Status register set contents (on
page E-1) and Enable and transition registers (on page E-19). The individual bits of this register are defined in
the following table.
Bit Value Description
B0
Not used
Not applicable
B1
status.operation.instrument.trigger_timer.trigger_overrun.TMR1
Bit B1 decimal
value: 2
B2
status.operation.instrument.trigger_timer.trigger_overrun.TMR2
Bit B2 decimal
value: 4
B3
status.operation.instrument.trigger_timer.trigger_overrun.TMR3
Bit B3 decimal
value: 8
B4
status.operation.instrument.trigger_timer.trigger_overrun.TMR4
Bit B4 decimal
value: 16
B5
status.operation.instrument.trigger_timer.trigger_overrun.TMR5
Bit B5 decimal
value: 32
B6
status.operation.instrument.trigger_timer.trigger_overrun.TMR6
Bit B6 decimal
value: 64
B7
status.operation.instrument.trigger_timer.trigger_overrun.TMR7
Bit B7 decimal
value: 128
B8
status.operation.instrument.trigger_timer.trigger_overrun.TMR8
Bit B8 decimal
value: 256
B9-B15
Not used
Not applicable
As an example, to set bit B1 of the operation status trigger timer trigger overrun enable register, set
status.operation.instrument.trigger_timer.trigger_overrun.enable =
status.operation.instrument.trigger_timer.trigger_overrun.TMR1.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the bit to set.
To set more than one bit of the register, set operationRegister to the sum of their decimal weights. For
example, to set bits B1 and B4, set operationRegister to 18 (which is the sum of 2 + 16).
Bit
B7
B6
B5
B4
B3
B2
B1
B0
Binary value
0/1
0/1
0/1
0/1
0/1
0/1
0/1
0/1
Decimal 128 64 32 16 8 4 2 1
Weights
(2
7
) (2
6
) (2
5
) (2
4
) (2
3
) (2
2
) (2
1
) (2
0
)
Bit
B15
B14
B13
B12
B11
B10
B9
B8
Binary value 0/1 0/1 0/1 0/1 0/1 0/1 0/1 0/1
Decimal
32,768
16,384
8,192
4,096
2,048
1,024
512
256
Weights
(2
15
) (2
14
) (2
13
) (2
12
) (2
11
) (2
10
) (2
9
) (2
8
)
Example
status.operation.instrument.trigger_timer.trigger_overrun.enable =
status.operation.instrument.trigger_timer.trigger_overrun.TMR3
Uses a
constant to
set the timer
3 bit of the
operation
status trigger
timer overrun
enable
register.
