1-8 Return to Section Topics 2600S-901-01 Rev. C / January 2008
Section 1: Getting Started Series 2600 System SourceMeter® Instruments Reference Manual
TRIG Triggers readings.
MENU Accesses the main menu for saving and recalling setups, selecting a remote interface, line
frequency, self-tests, serial number, and beeper control.
EXIT Cancels selection and backs out of menu structure. Also used as a LOCAL key to take the
unit out of remote.
ENTER Accepts selection and moves to the next choice or exits the menu.
3 Range keys:
and Selects the next higher or lower source or measure range.
AUTO Enables or disables source or measure auto range.
4 Output control and LED status indicator:
OUTPUT ON/OFF Turns source output on or off.
LED indicator Turns on when output is on.
5 Rotary knob and CURSOR keys:
When in source edit, use the CURSOR keys for cursor control, and then rotate the knob to change a
source or compliance value. The rotary knob can also be used to enable or disable the source edit mode.
When in a menu, use the CURSOR keys or rotary knob for menu item cursor control. When displaying a
menu value, use the CURSOR keys for cursor control and rotate the knob to change the value. Pressing
the knob opens a menu item or selects a menu option or value.
6 Display annunciators (not shown):
EDIT Unit is in the source editing mode
ERR Questionable reading or invalid cal step
REM Unit in remote mode
TALK Unit is addressed to talk
LSTN Unit is addressed to listen
SRQ Service request
REL Relative mode enabled
FILT Digital filter is enabled
AUTO Auto source or measure range is selected
ARM Unit is armed and ready to run
TRIG External triggering is selected
* (asterisk) Readings are being stored in the buffer
