13-8 Return to Section Topics 2600S-901-01 Rev. C / January 2008

Section 13: Factory Scripts Series 2600 System SourceMeter® Instruments Reference Manual

Example SweepILogMeasureV(smua, 0.01, 0.1, 0.001, 5)

This function performs a 5-point logarithmic current sweep starting at 10mA and

stopping at 100mA. Voltage is measured at every step (point) in the sweep. The

source will be allowed to settle on each step for 1ms before a measurement is

performed.

The following log values and corresponding source levels for the 5-point log

sweep are listed as follows:

MeasurePoint LogStepSize LogStep SourceStepLevel

1 0.25 0.0 0.01A

2 0.25 0.25 0.017783A

3 0.25 0.5 0.031623A

4 0.25 0.75 0.056234A

5 0.25 1.0 0.1A

Table 13-6

KIGeneral TSP test script: SweepVLogMeasureI

TSP project name: KIFactoryGeneral

TSP test script name: KIGeneral

Firmware version: 1.0.2 and later

Function:

SweepVLogMeasureI(smu, startv, stopv, stime, points)

Table 13-5 (continued)

KIGeneral TSP test script: SweepILogMeasureV

TSP project name: KIFactoryGeneral

TSP test script name: KIGeneral

Firmware version: 1.0.2 and later

Function:

SweepILogMeasureV(smu, starti, stopi, stime, points)
