2600S-901-01 Rev. C / January 2008 Return to Section Topics 13-29
Series 2600 System SourceMeter® Instruments Reference Manual Section 13: Factory Scripts
Example(s)
smua.reset()
smua.source.rangev = 5
smua.source.rangei = 1
smua.source.levelv = 0
smua.measure.rangev = 5
smua.measure.rangei = 1
smua.measure.nplc = 0.01
smua.measure.autozero = smua.AUTOZERO_ONCE
smua.nvbuffer1.clear()
smua.nvbuffer1.appendmode = 1
smua.source.output = smua.OUTPUT_ON
f1, msg1 = ConfigPulseVMeasureI(smua, 0, 5, 1, 0.002, 0.2,
10,smua.nvbuffer1, 1)
print(QueryPulseConfig(1).tostring())
Output from commands above
>> tag = 1
>> smu = smua
>> func = volts
>> type = pulse
>> bias = 0
>> level = 5
>> limit = 1
>> time on = 0.002
>> time off = 0.2
>> points = 10
>> measure = yes
>> sync_in = 0
>> sync_out = 0
>> sync_in_timeout = 0
>> sync_out_abort = 0
>> { 5, 5, 5, 5, 5, 5, 5, 5, 5, 5 }
Configure channel A to generate a pulse train then query configuration and
display as a string. Channel A will pulse voltage from a bias level of 0V to pulse
level of 5V. The pulse level will be present for 2msec and the bias level for 200
msec, with a 1A limit setting. A total of 10 pulses will be generated and the
measurement data will be stored in SMU A.nvbuffer1. This pulse train will be
assigned to tag = 1
Table 13-17 (continued)
KIGeneral TSP test script: QueryPulseConfig
TSP project name: KIFactoryPulse
TSP test script name: KIPulse
Firmware version: 1.2.0 and later
Function:
QueryPulseConfig
Usage:
tbl = QueryPulseConfig(tag)
