2600S-901-01 Rev. C / January 2008 Return to Section Topics 13-31
Series 2600 System SourceMeter® Instruments Reference Manual Section 13: Factory Scripts
Example(s)
smua.reset()
smua.source.rangev = 5
smua.source.rangei = 1
smua.source.levelv = 0
smua.measure.rangev = 5
smua.measure.rangei = 1
smua.measure.nplc = 0.01
smua.measure.autozero = smua.AUTOZERO_ONCE
smua.nvbuffer1.clear()
smua.nvbuffer1.appendmode = 1
smua.source.output = smua.OUTPUT_ON
f1, msg1 = ConfigPulseVMeasureI(smua, 0, 5, 1, 0.002, 0.2,
10,
smua.nvbuffer1, 1)
if (f1 == true) then
f2, msg2 = InitiatePulseTest(1)
print("Initiate message:", msg2)
else
print("Config errors:", msg1)
end
Example(s)
Configure SourceMeter channels A to generate a pulse train. If no errors are
encountered, initiate the pulse train. Channel A will pulse voltage from a bias level
of 0V to pulse level of 5V. The pulse level will be present for 2 msec and the bias
level for 200 msec, with a 1A limit setting. A total of 10 pulses will be generated
and the measurement data will be stored in smua.nvbuffer1. This pulse train
will be assigned to tag = 1.
See Also
ConfigPulseIMeasureV, ConfigPulseVMeasureI,
ConfigPulseIMeasureVSweepLin,
ConfigPulseVMeasureISweepLin,
ConfigPulseIMeasureVSweepLog,
ConfigPulseVMeasureISweepLog
Table 13-18 (continued)
KIGeneral TSP test script: InitiatePulseTest
TSP project name: KIFactoryPulse
TSP test script name: KIPulse
Firmware version: 1.2.0 and later
Function:
InitiatePulseTest
Usage:
f, msg = InitiatePulseTest(tag)
