Keithley 2635 Reference Manual

2600S-901-01 Rev. C / January 2008 Return to Section Topics 15-7
Series 2600 System SourceMeter® Instruments Reference Manual Section 15: Performance Verification
Figure 15-1
Connections for voltage verification
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
MADE IN
U.S.A.
IEEE-488
(CHANGE IEEE ADDRESS
WITH FRONT PANEL MENU)
LINE RATING
100-240VAC
50, 60Hz
240VA MAX.
DIGITAL I/O
RS-232
TSP-Link
LINE FUSE
SLOWBLOW
3.15A, 250V
CAT I
SS
LO LO HIHI GGGG
CHANNEL A
!
!
!
U
L
C
US
LISTED
SourceMeter
4ZA4
CAT I
S
S
LO
LO
HI
HI
G
G
G
G
CHANNEL B
!
R
Input HI
Input LO
Model 2602/2612 Channel A
Connections Shown
LO
HI
Digital Multimeter
S LO
S HI
CHANNEL B
SENSE
LO
LO
GUARD
SENSE
HI
HI
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
WARNING: NO INTERNAL OPERATOR SERVICABLE PARTS,SERVICE BY QUALIFIED PERSONNEL ONLY.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
CAUTION: FOR CONTINUED PROTECTION AGAINST FIRE HAZARD,REPLACE FUSE WITH SAME TYPE AND RATING.
MADE IN
U.S.A.
IEEE-488
LINE RATING
100-240VAC
50, 60Hz
240VA MAX.
DIGITAL I/O
RS-232
TSP-Link
LINE FUSE
SLOWBLOW
3.15A, 250V
!
A LOB LO
R
CHANNEL A
SENSE
LO
LO
GUARD
SENSE
HIHI
CHANNEL B
SENSE
LO
LO
GUARD
SENSE
HI
HI
Model 2636 channel A
connections shown
Input HI
Input LO
LO
HI
Digital Multimeter
S LO
S HI
2. Select the multimeter DC volts measuring function.
3. Select the Model 2602/2612/2636 single-channel display mode. Press the Series 2600 SRC
key to source voltage, and make sure the source output is turned on.
4. Enable the Series 2600 4-wire (remote sense) mode by pressing CONFIG then SRC, then
select V-SOURCE > SENSE-MODE > 4-WIRE.
5. Verify output voltage accuracy for each of the voltages listed in Table 15-2 (Model 2601/
2602) or Table 15-3 (Model 2611/2612/2635/2636). For each test point:
• Select the correct source range.
