Models 2611/2612
System SourceMeter
®
Specifications
Specifications are subject to change without notice.
Page 2 of 6 SPEC-2611_2612 Rev. A / June 2006
Current Programming Accuracy
4
Range
Programming
resolution
Accuracy (1 year)
23°C +
5°C
+
(% rdg.+amps)
Typical noise
(peak-peak)
0.1Hz-10Hz
100.000nA 2pA 0.06% + 100pA 5pA
1.00000ȝA 20pA 0.03% + 800pA 25pA
10.0000ȝA 200pA 0.03% + 5nA 60pA
100.000ȝA 2nA 0.03% + 60nA 3nA
1.00000mA 20nA 0.03% + 300nA 6nA
10.0000mA 200nA 0.03% + 6ȝA 200nA
100.000mA 2ȝA 0.03% + 30ȝA 600nA
1.00000A
2
20ȝA 0.05% + 1.8mA 70ȝA
1.50000A
2
50ȝA 0.06% + 4mA 150ȝA
10.0000A
2,5
200ȝA 0.5% + 40mA
Temperature coefficient (0°C–18°C and 28°C–50°C): ±(0.15 × accuracy specification)/°C.
Maximum output power and source/sink limits:
2
30.603W per channel maximum. ±1.515A at ±20.2V, ±101mA
at ±202V, four-quadrant source or sink operation.
Current regulation: Line: 0.01% of range. Load: ±(0.01% of range + 100pA).
Voltage limit/compliance:
6
Bipolar voltage limit (compliance) set with a single value. Minimum value is 10mV.
Accuracy same as voltage source.
Overshoot: <0.1% typical (step size = 10% to 90% of range, resistive load; see “Current source output settling
time” for additional test conditions).
Additional Source Specifications
Transient response time: <70ȝs for the output to recover to 0.1% for a 10% to 90% step change in load.
Voltage source output settling time: Time required to reach 0.1% of final value after source level command is processed on a
fixed range.
200mV, 2V ranges: <50ȝs typical. 20V range: <110ȝs typical. 200V range: <700ȝs typical.
Current source output settling time: Time required to reach 0.1% of final value after source level command is processed on a
fixed range. Values below for Iout · Rload = 2V unless noted.
1.5A–1A ranges: <120ȝs typical (Rload >6ȍ).
100mA–10mA ranges: <80ȝs typical.
1mA range: <100ȝs typical.
100ȝA range: <150ȝs typical.
4 Accuracy specifications do not include connector leakage. Derate accuracy by Vout/2E11 per °C when operating
between 18°C–28°C. Derate accuracy by Vout/2E11 + (0.15 * Vout/2E11) per °C when operating <18°C and >28°C.
5 10A range accessible only in pulse mode.
6 For sink mode operation (quadrants II and IV), add 10% of compliance range and ±0.02% of limit setting to corresponding
voltage source specification. For 200mV range add an additional 120mV of uncertainty.
