Keithley 2635 Reference Manual

Keithley Instruments, Inc.
28775 Aurora Road
Cleveland, Ohio 44139
1-888-KEITHLEY
www.keithley.com
Specifications are subject to change without notice.
SPEC-2611_2612 Rev. A / June 2006 Page 5 of 6
Models 2611/2612
System SourceMeter
®
Specifications
Current measurement accuracy
14,12
Range Display resolution
13
Voltage burden
15
Accuracy (1 year)
23°C +
5°C
+
(% rdg.+amps)
100.000nA 1pA <1mV 0.05% + 100pA
1.00000ȝA 10pA <1mV 0.025% + 500pA
10.0000ȝA 100pA <1mV 0.025% + 1.5nA
100.000ȝA 1nA <1mV 0.02% + 25nA
1.00000mA 10nA <1mV 0.02% + 200nA
10.0000mA 100nA <1mV 0.02% + 2.5ȝA
100.000mA 1ȝA <1mV 0.02% + 20ȝA
1.00000A 10ȝA <1mV 0.03% + 1.5mA
1.50000A 10ȝA <1mV 0.05% + 3.5mA
10.0000A
16
100ȝA <1mV 0.4% + 25mA
Temperature Coefficient (0°C–18°C and 28°C–50°C): ±(0.15 × accuracy specification)/°C.
Contact Check
17
Speed
Maximum measurement time to
memory for 60Hz (50Hz)
17
Accuracy (1 year)
23°C +
5°C
+
(% rdg.+ohms)
Fast 1 (1.2)ms 5% + 10
Medium 4 (5)ms 5% + 1
Slow 36 (42)ms 5% + 0.3
Additional Meter Specifications
Load impedance: Stable into 10,000pF typical.
Common mode voltage: 250VDC.
Common mode isolation: >1G, <4500pF.
Over-range: 101% of source range, 102% of measure range.
Maximum sense lead resistance: 1k for rated accuracy.
Sense input impedance: >10G.
14 De-rate accuracy by Vout/2E11 per °C when operating between 18°C–28°C. Derate accuracy by Vout/2E11 + (0.15 *
Vout/2E11) per °C when operating <18°C and >28°C.
15 Four-wire remote sense only.
16 10A range accessible only in pulse mode.
17 Includes measurement of SENSE HI to HI and SENSE LO to LO contact resistances.
