Keithley 2635 Reference Manual

2600S-901-01 Rev. C / January 2008 Return to Section Topics D-19
Series 2600 System SourceMeter® Instruments Reference Manual Appendix D: Status Model
To read registers:
print(status.operation.*)
print(status.operation.condition)
print(status.operation.event)
To set register bits:
status.operation.instrument.smuX.* = status.operation.CALIBRATING B0
status.operation.instrument.smuX.* = status.operation.CAL B0
status.operation.instrument.smuX.* = status.operation.MEASURING B4
status.operation.instrument.smuX.* = status.operation.MEAS B4
status.operation.instrument.smuX.* = status.operation.PROMPTS B11
status.operation.instrument.smuX.* = status.operation.PRMPTS B11
status.operation.instrument.smuX.* = status.operation.USER B12
status.operation.instrument.smuX.* = status.operation.PROGRAM_RUNNING B14
status.operation.instrument.smuX.* = status.operation.PROG B14
To read registers:
print(status.operation.instrument.smuX.*)
print(status.operation.instrument.smuX.condition)
print(status.operation.instrument.smuX.event)
To set register bits:
status.operation.instrument.* = status.operation.instrument.SMUA B1
status.operation.instrument.* = status.operation.instrument.SMUB B2
To read registers:
print(status.operation.instrument.*)
print(status.operation.instrument.condition)
print(status.operation.instrument.event)
To set register bits:
status.operation.calibrating.* = status.operation.calibrating.SMUA B1
status.operation.calibrating.* = status.operation.calibrating.SMUB B2
To read registers:
print(status.operation.calibrating.*)
print(status.operation.calibrating.condition)
print(status.operation.calibrating.event)
To set register bits:
status.operation.measuring.* = status.operation.measuring.SMUA B1
status.operation.measuring.* = status.operation.measuring.SMUB B2
To read registers:
print(status.operation.measuring.*)
print(status.operation.measuring.condition)
print(status.operation.measuring.event)
1. * = '.ntr', '.ptr' and '.enable'; smuX = smua or smub.
** = '.ntr', '.ptr', '.enable', and ‘.condition’; smuX = smua or smub.
Table D-7 (continued)
Operation event commands
Command
1
Bit
