Keithley 7001 Quick Reference Guide

12
TEST
BUILT-IN TESTS
AUTO
MANUAL
DISPLAY TESTS
KEYS
PATTERNS
Self-Test Menu:
Test Digital Board:
Run all tests automatically
Select tests to run
Test Display Board:
Verify operation of front panel
keys
Verify operation of display
LANGUAGE
ENGLISH
GERMAN
FRENCH
Choose Language:
Display messages in English.
Display messages in German.
Display messages in French.
GENERAL
SERIAL #
STATUS-MESSAGES
General Menu:
Displays serial number, SCPI ver-
sion, and software revision.
Enables/disables status message
mode.
Table 2: CONFIGURE SCAN menu structure
Menu item Description
CHAN-CONTROL
CHANNEL-SPACING
TIMER
EXTERNAL
GPIB
MANUAL
TRIGLINK
Configure Channel Layer:
Select channel spacing:
Use a timer to select each chan-
nel in the scan.
Use an external trigger to select
each channel.
Use a bus trigger to select each
channel.
Use STEP key to select each
channel.
Use a Trigger Link trigger to
select each channel.
Table 1: MAIN MENU structure (Cont.)
Menu item Description

Keithley 7001 Specifications

General

Brand	Keithley
Model	7001
Category	Switch
Language	English
