Keithley 7001 Quick Reference Guide

13
ASYNCHRONOUS
SEMI-SYNCHRONOUS
IMMEDIATE
HOLD
NUMBER-OF-CHANS
USE-SCANLIST-LENGTH
CHAN-COUNT
INFINITE
ENTER-CHAN-COUNT
CONTROL
SOURCE
ACCEPTOR
Use separate lines for In/Out
triggers.
Use same line for In/Out trig-
gers.
Use to scan channels immedi-
ately.
Use to hold up the scan in the
channel layer.
Define number of channels to
scan:
Count = number of channel
entries in scan list.
User defined count:
Repeat channel scanning
indefinitely.
Count = user defined value (1
to 9999)
Select trigger control mode:
Enable the Source Bypass.
Disable the Source Bypass.
SCAN-CONTROL
SCAN-SPACING
TIMER
EXTERNAL
GPIB
MANUAL
TRIGLINK
IMMEDIATE
HOLD
NUMBER-OF-SCANS
INFINITE
ENTER-SCAN-COUNT
Configure Scan Layer:
Select scan spacing:
Use the timer to control scan
spacing.
Use external triggers to control
scan spacing.
Use bus triggers to control scan
spacing.
Use STEP key to control scan
spacing.
Use Trigger Link triggers to con-
trol scan spacing.
Use to pass operation immedi-
ately into the channel layer.
Use to hold up the scan in the
scan layer.
Define number of scans to be per-
formed:
Repeat scan indefinitely.
Count = user defined value (1 to
9999).
Table 2: CONFIGURE SCAN menu structure (Cont.)
Menu item Description
