14
CONTROL
SOURCE
ACCEPTOR
Select trigger control mode:
Enable Source Bypass.
Disable Source Bypass.
ARM-CONTROL
ARM SPACING
MANUAL
IMMEDIATE
GPIB
EXTERNAL
TRIGLINK
HOLD
ARM-COUNT
INFINITE
ENTER-ARM-COUNT
TRIGGER-CONTROL
SOURCE
ACCEPTOR
Configure Arm Layer:
Select arm spacing control:
Use STEP key to arm scanner.
Use to arm scanner immediately.
Use a bus trigger to arm scanner.
Use an external trigger to arm
scanner.
Use a Trigger Link trigger to arm
scanner.
Use to hold up the scan in the
arm layer.
Define number of times to arm
scanner:
Continuously re-arm scanner.
User defined count value (1 to
9999).
Select trigger control mode:
Enable Source Bypass.
Disable Source Bypass.
CHAN-RESTRICTIONS
SINGLE-CHAN
RESTRICTED-CHANNELS
Define channel restrictions:
Enable/disable Single Channel
Mode.
Specify channels that cannot be
closed.
Table 2: CONFIGURE SCAN menu structure (Cont.)
Menu item Description
