Keithley S530 User Manual

Section
3: LPTLib command reference S530/S540 KTE Linear Parametric Test Library (LPTLib) User's Manual
3-80 S530-900-01 Rev. E / September 2017
Modifiers that affect CVU measurements
Modifier Value Comment
KI_CVU_ACV
<value>
10 mV to 100 mV (45 mV is default)
KI_CVU_ACZ_RANGE
<value>
0 = Autorange (default)
1e-6 = 1 µA range
30e-6 = 30 µA range
1e-3 = 1 mA range
KI_CVU_CORRECT LOAD
0 or 1
0 = Off (default)
1 = On
KI_CVU_CORRECT_OPEN
0 or 1
0 = Off (default)
1 = On
KI_CVU_CORRECT_SHORT
0 or 1
0 = Off (default)
1 = On
KI_CVU_FREQ
<value>
1 kHz to 2 MHz (100 kHz is default)
KI_CVU_LENGTH
KI_CVU_CABLE_CORR_LV
KI_CVU_CABLE_CORR_HV
KI_CVU_CABLE_CORR_LV_HV
Specifies the type of cables used in
the system so that cable-length
corrections can be automated.
KI_CVU_MODE
0 or 1
0 = User mode
1 = System mode (default)
KI_CVU_MODEL
0 to 5
0 = Z, theta
1 = R, jx
2 = Cp, Gp (default)
3 = Cs, Rs
4 = Cp, D
5 = Cs, D
KI_CVU_SPEED
0 to 2
0
= Fast (default)
1 = Normal
2 = Quiet
Does not affect the intgc, intgg
,
o
r intgcg LPT commands. T
o
adjust the speed of these LPT
commands, use the KI_INTGPLC
setmode.
Modifiers that affect matrix operation
Modifier Value Comment
KI_AUTO_GND_PINS
70xB: 0 or 1
Enable or disable the feature that
automatically connects all unused
pins to GND (including the
CHUCK).
0 = Disable
1 = Enable
