Modifiers that affect source-measure unit (SMU) behavior (continued)
Modifier Value Comment
KI_VMTR
Sets up a SMU as a voltmeter.
The ranges used are
representative of the type of
instrument being simulated.
Note that this setmode turns
on the source.
KI_S400
Sets a SMU to use ranges
equivalent to the S400.
KI_DMM
Sets a SMU to use ranges
equivalent to a DMM. Provides
a low impedance, fast
measurements. Used for
low-voltage applications.
KI_ELECTROMETER
Sets a SMU to use ranges
equivalent to an electrometer.
Provides high input impedance
but has slower measurement
time. Used for high-resistance
measurements.
KI_2600_ANALOG_FILTER
26xx:
KI_ON
KI_OFF
Turns the analog filter on or off
for a specified SMU.
Modifiers that affect triggering
Modifier Value Comment
KI_AVGNUMBER
<value>
Number of readings to make
when KI_TRIGMODE is set to
KI_AVERAGE
.
KI_AVGTIME
<value> Time between readings when
KI_TRIGMODE is set to
KI_AVERAGE.
KI_TRIGMODE
KI_MEASX
KI_INTEGRATE
KI_AVERAGE
Redefines all existing triggers to
use a new method of
measurement.
KI_ABSOLUTE
KI_NORMAL
Use absolute value or polarized
readings for trigger condition.
