22
SEE NOTES
LINK
HD
C
NO
RELAY 1
R
REMOTE
INPUT
LOW VOLTAGE
NO
C
RELAY 2
LV
SUPPLY
MAINS
SUPPLY
A
N
N
L1
L2
L3
COIL
PUMP
A1 A2
CONTACTOR
WARNING
Contactor coil rating must
not exceed 240VAC
BASIC 3 PHASE PUMP CONTROL
3 PHASE CONTROL WITH ALARM & REMOTE INPUT
SEE NOTES
LINK
HD
C
NO
RELAY 1
R
REMOTE
INPUT
LOW VOLTAGE
NO
C
RELAY 2
LV
SUPPLY
MAINS
SUPPLY
A
N
PUMP
ALARM
16A 240V Maximum
resistive load
REMOTE INPUT
with voltage free
contacts
CONTACTOR
N
L1
L2
L3
COIL
A1 A2
WARNING
Contactor coil rating must
not exceed 240VAC
