KELCO E30 - Page 7

7
M4 Allen head locking
screw
Wall bracket
locking bolt
Process Connection 1/4” BSPF
Locking screw
O-ring seal must be in
place, clean and in
good order.
Process connector screwed
onto a 1/4”BSP nipple in turn
screwed into a pipe tapping
point
E30 electrical head
1/4” BSP nipple (not
included)
Typical tapping point on a section of pipe
