GENERAL DESCRIPTION
1
The KELLER Intelligent Manometer is a precise
pressure measuring instrument. Its high accu-
racy, solid construction and its long battery life
make it to an ideal measuring instrument, espe-
cially for measuring tasks where independence
and flexibility are required.
In its standard version, the pressure transducer
is built into the housing as shown below. The
transducer is retained with a counternut.
Mounting:
Screw the male port of the Intelligent Mano-
meter into the female pressure port and tighten
using the lower hexagon of the transducer.
Adjusting the face:
Loosen the upper hexagon of the counternut
and rotate the Intelligent Manometer to the desi-
red position. Retighten.
The face of the Intelligent Manometer can be
rotated through 355°. This feature allows the
Intelligent Manometer to be mounted in all pos-
sible positions; vertical, horizontal or upside
down.
The splash-proof cover of the Intelligent Mano-
meter is sealed with an O-ring and may easily
be removed by hand by turning the display ring
beyond the limit stop (see “Battery Change” in
Chapter “Notes
”
” on page 12).
