DISE-MODE
6
(MANO RECORD ONLY)
Display Select enables the selection of the dis-
play position, and allocates the measured para-
meter to the chosen display.
There are three selectable display positions:
Upper Display / Lower Left / Lower Right.
These displays can be occupied by the follo-
wing variables:
Symbol Variable
1 Sensor 1
2 Sensor 2 (only if two sensors
are connected)
1-2 Difference (only if two sensors
are connected)
HIGH Peak Value for Sensor 1*
LOW Trough Value for Sensor 1*
25° Temperature
00:00 Time Meter
*If this variable is selected, the
instrument will always measure
in a 1/2-second interval, indepen-
dent from the set measuring cycle.
The selected configuration is valid for both the
Mano-Mode and the Record-Mode.
Please note that not all possible combinations
are programmable.
DISE (DIsplay SElect) = Selection of Display
