3. Outer frame assembly
3.2 Outer frame assembly
3.2.16
Check outer frame alignment again after fixing and fine
tune if necessary to ensure perfect installation.
If elements are installed according to
EN 1627 (burglar resistance) a
pressure resistant shimming must be
added behind the outer frame.
