16
Keller minimal windows
®
Keller minimal windows
®
4+ 03
On-site installation | 997-000120 | 07-2021
3. Outer frame assembly
3.2 Outer frame assembly
3.2.14
Insert fixing bushings and fix outer frame with adjustment
screws.
3.2.15
Regularly check outer frame alignment with 5-point laser.
